RGBlink aura UHD studio 24 (Gen 2)
Produkto numeris: 50638
Produktas užsakomas. Pristatymo laikas nuo 3 savaičių.
The RGBlink Aura UHD Studio 24 Gen 2 is a 23.8” professional 4K HDR broadcast-grade monitor designed for post-production and live production workflows. It features quad 12G-SDI monitoring, Thunderbolt™ connectivity for app previews, high-precision 3D LUT support, HDR waveform, ARRI/Red false color, and independent color modes per window.
The RGBlink Aura UHD Studio 24 Gen 2 is a next-generation 23.8” UHD 4K HDR IPS monitor built for broadcast, film, and professional post-production workflows. The monitor delivers 3840 × 2160 resolution, 1000-nit brightness, and full 100% DCI-P3 wide color gamut, providing precise and consistent color for critical production work. The 10-bit IPS panel supports HDR gamma curves including PQ, HLG, and S-Log3, as well as camera Log formats, with custom 3D LUT import using a tetrahedral interpolation algorithm for accurate color matching across multiple displays.
Compared to the first generation, the Studio 24 Gen 2 enables quad-view monitoring of four 12G-SDI signals simultaneously, with each window capable of selecting an independent color mode and displaying corresponding audio pillars. The monitor also supports HDR waveform analysis and false color with ARRI and Red camera profiles. A standout feature of the Studio series is direct app preview via Thunderbolt™, allowing live monitoring of outputs from DaVinci Resolve™ or Adobe Premiere Pro™. Additional professional features include DC 24V XLR power, V-mount battery support, and circuits optimized for energy efficiency, ESD, and EMI. With its combination of high brightness, color accuracy, and advanced workflow integration, the Aura UHD Studio 24 Gen 2 is ideal for film, TV, advertising, and post-production environments.
Key Features:
- 23.8” UHD 4K IPS LCD panel
- 1000-nit high brightness
- 100% DCI-P3 wide color gamut
- Quad 12G-SDI monitoring with independent color mode per window
- HDR waveform and false color support (ARRI & Red)
- Custom 3D LUT import (tetrahedral interpolation)
- Thunderbolt™ connectivity for preview of DaVinci Resolve™ and Adobe Premiere Pro™ outputs
- Audio pillars per window in quad-view
- DC 24V XLR power, V-mount battery compatible
- Energy-saving, ESD & EMI-optimized circuits
- Supports PQ, HLG, S-Log3, and camera Log gamma curves
- RGBlink Aura UHD Studio 24 Gen 2 Monitor
- DC 24V XLR power cable
- User documentation
- Display Size: 23.8″
- Resolution: 3840 × 2160 (UHD 4K)
- Panel Type: IPS LCD
- Aspect Ratio: 16:9
- Brightness: 1000 cd/m²
- Color Gamut: 100% DCI-P3
- HDR Support: PQ, HLG, S-Log3
- LUT Support: High-precision 3D LUT with tetrahedral interpolation
- Video Inputs: 4 × 12G-SDI (quad-view)
- Audio: Audio pillars per window
- Thunderbolt™ Port: Live app preview (DaVinci Resolve™, Adobe Premiere Pro™)
- Power: DC 24V XLR, V-mount battery compatible
- Features: Quad-view multi-window support, independent color mode per window, HDR waveform, ARRI/Red false color, energy-saving, ESD & EMI-optimized circuits
- Package Contents: RGBlink Aura UHD Studio 24 Gen 2 Monitor, DC 24V XLR power cable, user documentation
| Type of Product | LCD Monitor |
| LCD monitors | monitors |
| Connector | Thunderbolt |
| Connector | SDI |
The RGBlink Aura UHD Studio 24 Gen 2 is a 23.8” professional 4K HDR broadcast-grade monitor designed for post-production and live production workflows. It features quad 12G-SDI monitoring, Thunderbolt™ connectivity for app previews, high-precision 3D LUT support, HDR waveform, ARRI/Red false color, and independent color modes per window.
The RGBlink Aura UHD Studio 24 Gen 2 is a next-generation 23.8” UHD 4K HDR IPS monitor built for broadcast, film, and professional post-production workflows. The monitor delivers 3840 × 2160 resolution, 1000-nit brightness, and full 100% DCI-P3 wide color gamut, providing precise and consistent color for critical production work. The 10-bit IPS panel supports HDR gamma curves including PQ, HLG, and S-Log3, as well as camera Log formats, with custom 3D LUT import using a tetrahedral interpolation algorithm for accurate color matching across multiple displays.
Compared to the first generation, the Studio 24 Gen 2 enables quad-view monitoring of four 12G-SDI signals simultaneously, with each window capable of selecting an independent color mode and displaying corresponding audio pillars. The monitor also supports HDR waveform analysis and false color with ARRI and Red camera profiles. A standout feature of the Studio series is direct app preview via Thunderbolt™, allowing live monitoring of outputs from DaVinci Resolve™ or Adobe Premiere Pro™. Additional professional features include DC 24V XLR power, V-mount battery support, and circuits optimized for energy efficiency, ESD, and EMI. With its combination of high brightness, color accuracy, and advanced workflow integration, the Aura UHD Studio 24 Gen 2 is ideal for film, TV, advertising, and post-production environments.
Key Features:
- 23.8” UHD 4K IPS LCD panel
- 1000-nit high brightness
- 100% DCI-P3 wide color gamut
- Quad 12G-SDI monitoring with independent color mode per window
- HDR waveform and false color support (ARRI & Red)
- Custom 3D LUT import (tetrahedral interpolation)
- Thunderbolt™ connectivity for preview of DaVinci Resolve™ and Adobe Premiere Pro™ outputs
- Audio pillars per window in quad-view
- DC 24V XLR power, V-mount battery compatible
- Energy-saving, ESD & EMI-optimized circuits
- Supports PQ, HLG, S-Log3, and camera Log gamma curves
- RGBlink Aura UHD Studio 24 Gen 2 Monitor
- DC 24V XLR power cable
- User documentation
- Display Size: 23.8″
- Resolution: 3840 × 2160 (UHD 4K)
- Panel Type: IPS LCD
- Aspect Ratio: 16:9
- Brightness: 1000 cd/m²
- Color Gamut: 100% DCI-P3
- HDR Support: PQ, HLG, S-Log3
- LUT Support: High-precision 3D LUT with tetrahedral interpolation
- Video Inputs: 4 × 12G-SDI (quad-view)
- Audio: Audio pillars per window
- Thunderbolt™ Port: Live app preview (DaVinci Resolve™, Adobe Premiere Pro™)
- Power: DC 24V XLR, V-mount battery compatible
- Features: Quad-view multi-window support, independent color mode per window, HDR waveform, ARRI/Red false color, energy-saving, ESD & EMI-optimized circuits
- Package Contents: RGBlink Aura UHD Studio 24 Gen 2 Monitor, DC 24V XLR power cable, user documentation
