SMALLRIG 4752 240W 4-PORT PD POWER ADAPTER 4752

Compact and convenient for travel and everyday use
The SmallRig 4752 240W 4 Port PD Power Adapter (EU Standard)  is a highly efficient and versatile charging device with a total output power of 240W. With four USB C ports, this charger supports simultaneous charging of multiple devices such as V mount batteries, NP F batteries, rechargeable camera batteries, smartphones, computers, cameras and more, making it suitable for different usage scenarios.


Highlights

High output power of 240W
Fast charging
Compatible with multiple devices

Fast charging
All ports support fast charging, with each port supporting up to 140W (Max) output via PD3.1, supporting powerful devices and significantly improving charging efficiency.


Power protection
Each port is equipped with short circuit and over current protection for safe use. Moreover, the chargers compact size makes it convenient for travel and daily use. ,

Weight (including cable): 664,0 g
Dimensions: 122.0 x 88.0 x 35.0 mm
Material: PC
Total output power: 240W
Input voltage: 100 240VAC 50/60Hz 4.0A

Output Power:
Single Port Mode:

USB C1 / C2 / C3 / C4:
5V3A 9V3A 5V5A 20V5A 28V5A
Total: 140W MAX

Mode dual port:

C1 + C2 / C3 + C4:
100W + 40W / 40W + 100W / 70W + 70W
Total: 140W MAX
C1 + C3 / C1 + C4 / C2 + C3 / C2 + C4:
140W + 100W
Total: 240W Max

Three port mode:

USB C1 + C2 + C3 / C1 + C2 + C4:
70W + 70W + 100W / 100W + 40W + 100W / 40W + 100W + 100W
Total: 240W Max
C2 + C3 + C4 / C1 + C3 + C4
140W + 60W + 40W / 140W + 40W + 60W / 140W + 50W + 50W
Total: 240w MAX

Quadruple port mode:

USB C1 + C2 + C3 + C4:
100W + 40W + 60W + 40W / 100W + 40W + 40W + 60W / 100W + 40W + 50W + 50W / 70W + 70W + 50W + 50W / 70W + 70W + 60W + 40W / 70W + 70W + 40W + 60W + 40W + 100W + 40W + 60W + 40W + 40W + 40W + 60W + 40W + 40W + 40W + 60W + 60W + 40W + 40W + 40W + 40W + 40W + 40W + 40W + 40W + 40W + 40W + 40W + 50W + 50W
Total: 240W Maximum
,

1 x SmallRig 4752 240W 4 Port PD Power Adapter (EU Standard)
