DATAVIDEO DAC-45 4K UP/DOWN/CROSS CONVERTER DAC-45

4K Up/Down Cross Converter

4K up conversion
With built-in super resolution engine, users can now up-convert from SD 480 resolution all the way to 4K resolution with excellent image quality and sharpness.

Wide range conversion for great compatibility
Supports VGA/HDMI/SDI to 4K HDMI/3G-SDI multi-format up/down/cross conversion.

External audio embedding
RCA inputs allow audio to be embedded to the output of the video signal.

Supports 3G-SDI Level A/B
With the 3G-SDI system, it supports both 3G-SDI Level A/B input.

Reference input (Black Burst and Tri-Level Sync.)
Supports Black Burst and Tri-Level Sync for all inputs.

Built-in De-interlacer and Interlacer (I/P conversion)
Supports I/P conversion to avoid the dense misaligned horizontal lines on the video.

**Adjustment of HDMI color space **
The DAC CENTER software allows adjustment of HDMI color space. Support of various resolutions and HDMI color space allow consumer laptops to be used in a professional workflow.

Easy installation on the rack
Available RMK-1 rack allows two DAC-45 to be racketed in a 19” rack.

In the box

• 1 x DAC-45
• 1 x AD Switch DC 12V
