Lilliput 45288 V7
Pristatymas per 5 - 7 dienas
The Lilliput V7 is a 7" 1920×1200 4K HDMI monitor with Voice Control (hands-free waveform, LUTs, false color), 450 nits, 100% BT.709, HDMI 2.0 in/loop-out, USB-C PD power, NP-F battery plate and pro tools. Ultra-thin 25 mm, 320 g—perfect for gimbal, handheld, and on-set use.
The Lilliput V7 7-inch 4K HDMI Voice Control Camera Monitor revolutionizes on-set monitoring with hands-free voice commands (≤1 m, ≥50 dB): switch waveforms, false color, peaking, load 3D LUTs, or adjust settings without touching the screen—ideal for gloved hands, sterile environments, or one-person crews. Its 1920×1200 IPS panel delivers 450 nits brightness, 1200:1 contrast, 160° viewing angles, and 100% BT.709 color space with HDR HLG/ST2084 (300/1000/10000) support for accurate exposure and color in any light. HDMI 2.0 input/loop-out handles up to 4K60 cleanly, while built-in tools include waveform, vectorscope, histogram, false color, zebra, focus peaking, anamorphic de-squeeze, and 8-channel audio meters. Power options are ultra-flexible: DC 7–24 V barrel, USB-C PD (5V/9V/12V/15V/20V), or Sony NP-F batteries (plate included). At just 25 mm thick and 320 g, with full metal housing and 1/4"-20 mounts on three sides, it’s perfect for gimbals, shoulder rigs, or director cages. The V7 is the ultimate compact, voice-activated field monitor for RED, ARRI, Sony FX, and Blackmagic shooters.
Key Features:
- Voice Control (≤1 m): “Show waveform”, “False color”, “Load LUT 1”, “Peaking on”, etc.
- 7" 1920×1200 IPS, 450 nits, 1200:1, 100% BT.709, HDR HLG/ST2084
- HDMI 2.0 in + loop-out (4K60, 1080p120 compatible)
- Full pro toolset: waveform, vectorscope, histogram, false color, zebra, peaking, audio meters
- 3D LUT import (USB-C), anamorphic de-squeeze (1.3x–2.0x)
- Power: USB-C PD, DC 7–24 V, or NP-F battery plate
- Ultra-thin 25 mm metal body, 320 g, 3× 1/4"-20 mounts
- 3.5 mm headphone jack + built-in speaker
- Model: Lilliput V7
- Panel: 7" IPS, 1920×1200 (16:10)
- Brightness: 450 cd/m²
- Contrast: 1200:1
- Viewing Angle: 160°/160° (H/V)
- Color Space: 100% BT.709
- HDR: HLG / ST2084 (300/1000/10000)
- Input: 1× HDMI 2.0 (4K60)
- Output: 1× HDMI 2.0 loop-through
- Audio: 8-ch HDMI embedded, 3.5 mm headphone
- Power Consumption: ≤14 W
- Power Input: DC 7–24 V (barrel), USB-C PD (5–20 V), NP-F battery plate
- Operating Temp: 0–50 °C
- Dimensions (L×W×D): 186.2 × 121 × 25 mm
- Weight: 320 g
- Mounting: 3× 1/4"-20 (left, right, bottom)
| Type of Product | LCD Monitor |
| Battery type | Sony NP-F550 |
| Connector | USB-C |
| Connector | USB-C įkrovimas/ryšys |
| Connector | HDMI |
The Lilliput V7 is a 7" 1920×1200 4K HDMI monitor with Voice Control (hands-free waveform, LUTs, false color), 450 nits, 100% BT.709, HDMI 2.0 in/loop-out, USB-C PD power, NP-F battery plate and pro tools. Ultra-thin 25 mm, 320 g—perfect for gimbal, handheld, and on-set use.
The Lilliput V7 7-inch 4K HDMI Voice Control Camera Monitor revolutionizes on-set monitoring with hands-free voice commands (≤1 m, ≥50 dB): switch waveforms, false color, peaking, load 3D LUTs, or adjust settings without touching the screen—ideal for gloved hands, sterile environments, or one-person crews. Its 1920×1200 IPS panel delivers 450 nits brightness, 1200:1 contrast, 160° viewing angles, and 100% BT.709 color space with HDR HLG/ST2084 (300/1000/10000) support for accurate exposure and color in any light. HDMI 2.0 input/loop-out handles up to 4K60 cleanly, while built-in tools include waveform, vectorscope, histogram, false color, zebra, focus peaking, anamorphic de-squeeze, and 8-channel audio meters. Power options are ultra-flexible: DC 7–24 V barrel, USB-C PD (5V/9V/12V/15V/20V), or Sony NP-F batteries (plate included). At just 25 mm thick and 320 g, with full metal housing and 1/4"-20 mounts on three sides, it’s perfect for gimbals, shoulder rigs, or director cages. The V7 is the ultimate compact, voice-activated field monitor for RED, ARRI, Sony FX, and Blackmagic shooters.
Key Features:
- Voice Control (≤1 m): “Show waveform”, “False color”, “Load LUT 1”, “Peaking on”, etc.
- 7" 1920×1200 IPS, 450 nits, 1200:1, 100% BT.709, HDR HLG/ST2084
- HDMI 2.0 in + loop-out (4K60, 1080p120 compatible)
- Full pro toolset: waveform, vectorscope, histogram, false color, zebra, peaking, audio meters
- 3D LUT import (USB-C), anamorphic de-squeeze (1.3x–2.0x)
- Power: USB-C PD, DC 7–24 V, or NP-F battery plate
- Ultra-thin 25 mm metal body, 320 g, 3× 1/4"-20 mounts
- 3.5 mm headphone jack + built-in speaker
- Model: Lilliput V7
- Panel: 7" IPS, 1920×1200 (16:10)
- Brightness: 450 cd/m²
- Contrast: 1200:1
- Viewing Angle: 160°/160° (H/V)
- Color Space: 100% BT.709
- HDR: HLG / ST2084 (300/1000/10000)
- Input: 1× HDMI 2.0 (4K60)
- Output: 1× HDMI 2.0 loop-through
- Audio: 8-ch HDMI embedded, 3.5 mm headphone
- Power Consumption: ≤14 W
- Power Input: DC 7–24 V (barrel), USB-C PD (5–20 V), NP-F battery plate
- Operating Temp: 0–50 °C
- Dimensions (L×W×D): 186.2 × 121 × 25 mm
- Weight: 320 g
- Mounting: 3× 1/4"-20 (left, right, bottom)
