SmallHD Indie 5 Inch Touchscreen Monitor RED RCP2Kit (RED KOMODO, DSMC3)

SmallHD Indie 5 Inch Touchscreen Monitor RED RCP2Kit (RED KOMODO, DSMC3)

Introducing the Indie 5 RED® RCP2™ Kit, the latest addition to our Smart 5 Series of monitors. As our smallest and lightest monitor, the Indie 5 packs a punch with its powerful features and sleek design.

With its hyper-responsive touchscreen display, the Indie 5 delivers stunning visuals with a brightness of 1000 nits and 1080p resolution. It also comes equipped with our intuitive PageOS 5 operating system, which provides quick access to all your favorite tools for effortless navigation.

Take control of your camera with the Indie 5's RED® RCP2™ camera-control functionality. This kit includes our RED® RCP2™ software license and control cables, which enable real-time configuration of RED® RCP2™ cameras such as KOMODO-X, KOMODO®, DSMC3™, and V-RAPTOR™. Quickly access essential camera settings with our user-friendly controls, and transform your touchscreen into the central command hub of your camera.

Whether you're a professional on an indie budget or just starting out, the Indie 5 is the perfect entry-level monitor for you. Its integrated tools provide more accurate exposure and color control, Look-Around Camera Control, EL Zone, Advanced Teradek RT overlays, and so much more.

Technical Specifications

• SKU: 16-0525-R2
• Product ID: 6808914985093
• Environmental:
• Item Weight (kg): 14.4
• Height (Inches): 3.39
• Width (Inches): 5.28
• Length/Depth (Inches): 1.52
• Mount Points: 6x 1/4-20 Mounting Points
• Display
• Panel Type: Touch-Screen
• Resolution: 1920 x 1080
• Aspect Ratio: 16:9
• Max Brightness: 1000 nits
• Backlight Type: Edgelit
• Input Signal
• 3G-SDI Input Types: YCC 422 10-bits 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i100
• HD-SDI Input Types: YCC 422 10-bits 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98
• SD-SDI Input Types: YCC 422 10-bits 480i59.94, 576i50
• HDMI Input Types: YCC 422 12 bits, 8 bit color in RGB & YCC 444 2160p30, 2160p29.97, 2160p25, 2160p24, 2160p23.98, 1080p120, 1080p119.88, 1080p100, 1080i120, 1080i119.88, 1080i100, 1080i60, 1080i59.94, 1080i50, 720p240, 720p239.76, 720p200 YCC 422 12 bits, 8/10/12/16 bit color in RGB & YCC 444 1080p60, 1080p59.94, 1080p50, 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 720p120, 720p119.88, 720p100, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 480p240, 480p239.76, 480p120, 480p119.88, 480p60, 480p59.94, 576p200, 576p100, 576p50, 480i240, 480i239.76, 480i120, 480i119.88, 480i60, 480i59.94, 576i200, 576i100, 576i50
• Audio Input Types: HDMI & SDI - Monitor through Speakers in Front Bezel or Through Headphone Jack - Metering up to 8 channels
• Output Signal
• 3G-SDI Output Types: YCC 422 10-bits 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i100
• HD-SDI Output Types: YCC 422 10-bits 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98
• SD-SDI Output Types: YCC 422 10-bits 480i59.94, 576i50
• HDMI Output Types: YCC 422 12 bits, 8 bit color in RGB & YCC 444 2160p30, 2160p29.97, 2160p25, 2160p24, 2160p23.98, 1080p120, 1080p119.88, 1080p100, 1080i120, 1080i119.88, 1080i100, 1080i60, 1080i59.94, 1080i50, 720p240, 720p239.76, 720p200 YCC 422 12 bits, 8/10/12/16 bit color in RGB & YCC 444 1080p60, 1080p59.94, 1080p50, 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 720p120, 720p119.88, 720p100, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 480p240, 480p239.76, 480p120, 480p119.88, 480p60, 480p59.94, 576p200, 576p100, 576p50, 480i240, 480i239.76, 480i120, 480i119.88, 480i60, 480i59.94, 576i200, 576i100, 576i50
• Audio Output Types: HDMI & SDI - Incoming Audio Stream is sent downstream via HDMI or SDI connection
• Connector Type
• SDI: 1x 3G-SDI (In), 1x 3G-SDI (In/Out)
• HDMI: 1x HDMI 2.0 (4Kp30) In, 1x HDMI 2.0 (4Kp30) Out
• Audio: 1x 3.5mm Stereo Headphone Jack
• Data I/O
• Storage Media: 1x SD Card Slot
• USB: 1x Micro USB
• Power
• Input: Barrel Power Input
• Software
• Pixel Zoom: Yes
• Focus Assist: Yes
• Peaking: Yes
• False Color: Customizable False Color Overlays
• Waveform: Customizable 4K Waveform w/Region of Interest Highlighting (Coming Soon)
• Custom LUTS: 17pt 3D-LUT on Output/Input, 33pt 3D-LUT on Output/Input

Included in Delivery

Indie 5 Inch Touchscreen Monitor RED
