WesternDigital Western Digital WD Red Plus 8TB (5640rpm) 256MB SATA 6Gb/s

Western Digital WD Red Plus 8TB

Overview

WD Red Plus drives are tailored for power users and small to medium business NAS environments, offering the speed and capacity needed for mid-sized RAID-optimized systems with enhanced power efficiency.

Key Features

• Ideal for power users and commercial NAS systems
• Supports RAID-optimized NAS systems with up to 8 bays
• Rated for 180TB/year workloads and up to 1M hours MTBF

Performance and Reliability

Tuned for NAS
Exclusive NASware technology optimizes drive parameters for improved performance and reliability.

Continuous Operation
Designed for 24x7 operation, ensuring reliable data access.

Compatibility
Extensively tested with various NAS vendors for dependable compatibility.

Lower TCO
Engineered for reduced power consumption and cooler operation, lowering operating costs.

Strong Performance
Handles mixed performance demands efficiently.

Increased Reliability
Enhanced dual-plane balance control technology minimizes vibration and noise, improving lifespan and performance.

Specifications

• Capacity: 8 TB
• Form Factor: 3.5-Inch
• Interface: SATA
• Transfer Rate: up to 215MB/s
• Disk Speed: 5640 RPM
• Cache Size: 256MB
• Warranty: 3-Year Limited Warranty
• Dimensions: 147mm x 101.6mm x 26.1mm
• Weight: 0.57 kg
• Model Number: WD80EFPX
• Operating Temperature: 0C to 65C
• Non-Operating Temperature: -40C to 70C

Disclosures
Workload Rate is defined as the amount of user data transferred to or from the hard drive, annualized based on power-on hours.
