Marshall Electronics CV620-WI 20x Optical Zoom Camera Kit
SKU: 51815
Būklė: Naujas produktas
Šiuo metu šio produkto negalima užsisakyti, prašome patikrinti vėliau.
€ 2 259.95 su mokesčiais
| Camera set | with lens (kit) |
Marshall Electronics CV620-WI
The Marshall CV620-BI/WI has a 20x optical zoom range. Video can be output simultaneously via IP, 3GSDI, and HDMI. The 2MP Sony sensor delivers clear images and brilliant colours up to 1920x1080p at 60fps. Camera movements and image settings can be controlled via Marshalls own web interface, OBS, vMix, the VS-PTC-IP joystick controller. The camera can also be operated via Vica over IP, RS-232 and RS-422 using control panels and software from other suppliers.
Helpful for initial set-up:
An IR remote control is included in the scope of delivery. All picture settings can be made via a menu that appears (similar to teletext). The control of presets and simple movements are also possible with the remote control.
The camera is available in two colours:
- Black (CV620-BI)
- White (CV620-WI)
Technical Specifications
- Sensor & Lens
- Sony IMX327
2 Megapixel (1/2.8)
20-fach optical zoom (5.3~110mm)
AOV: 60°(Wide) to 3° (Tele)
Focos Area: Recommended for sharp shots from a distance of 1.5 m
Minimum Illumination: 1.0 lux (F1.6, 50IRE, 30fps)
Aperture: F1.6~F3.6 - Resolution and frame rates
- 1920 x 1080p (60 / 30 / 59,94 / 29,97 / 50 / 25 fps)
1280 x 720p (60 / 59,94 / 50 fps) - Connectivity
- IP
3G-SDI
HDMI
RS232
RS422
3.5mm Audio Input with Passthrough - Control
- Steuerprotokoll: ONVIF, VISCA, PELCO D
Panning Speed: 120° / Second
Panning Angle:: 170° - Video Stream
- RTSP
RTMP
RTMPS
SRT
MPEG-TS - Video Compression
- H264: 25/30/50/60 fps 1080p/720p
MJPEG 1080p 30/15 fps - Image Settings
- Image Flip (Mirroring horizontally, vertically & both combined)
Focus System (Auto, One-push AF, Manual)
Gain Control (Auto/Manual)
White Balance (Auto/Manual)
Exposure Control (Auto/Manual)
3D NR - Audio
- Input: Line in/ Mic in
Output: Ethernet / SDI / HDMI - Dimensions & Weight
- 185mm x 186mm x 174mm
1.9kg - Power Supply
- DC: 16W max.
PoE+: 18W max.
Delivery Content
- Camera
- Adapter plate for ceiling mounting
- IR Remote
- Power Supply and Power Cord
