DZOFILM Tango 2-Lens Kit (18-90mm T2.9/65-280mm T2.9-4) for PL&EF Mount (S35) metric (w/o servo)

DZOFILM

SKU: 13901

Būklė: Naujas produktas

Šiuo metu šio produkto negalima užsisakyti, prašome patikrinti vėliau.

€ 16 227.64 su mokesčiais

Lens mountArri PL/Canon EF
Lens Format CoverageFull Frame
Lens DesignZoom Lenses
Lens focus length, mm65-280
Lens focus length, mm18-90
Focus TypeManual Focus
Image StabilizationNo
Lens typeLens Kit
Maximum ApertureT2.9

DZOFILM Tango 2-Lens Kit (18-90mm T2.9/65-280mm T2.9-4) for PL&EF Mount (S35) metric (without servo)

The concept of DZOFILM is to explore more possibility and incorporate it into daily filming and thinking. At DZOFILM it is all about the interaction and  the relationship between the cinematographer and their projects.

There is no need to look for other cine-lenses or hesitate. DZOFILM is dedicated to balance the harmony between aesthetics and utility and keep their cine-lenses compact and versatile. This way DZOFILM cine-lenses are enabling a swift and fast workflow and amazing footage.

  • 18-90mm and 65-280mm
  • Interchangeable PL and EF mount
  • Zoom factor: 4.3x/5x

Versatile Coverage, Unlimited Perspective

The Tango series offers an impressive range of focal lengths, from wide-angle to telephoto, allowing filmmakers to capture everything from sweeping landscapes to intimate close-ups with stunning details. With focal lengths spanning from 18mm to 280mm, the Tango lineup provides filmmakers with versatility and endless creative possibilities. The 18-90mm lens has a consistent T2.9 aperture throughout its 5x zoom range, while the 65-280mm lens boasts a T2.9 to T4 aperture with a 4.3x zoom ratio.

Aesthetic Bokeh, Captivating Visual
With a 16-blade aperture diaphragm, the Tango Zoom series produces smooth and alluring bokeh, drawing viewers into a world of visual storytelling. Its exceptional color rendition brings lifelike skin tones to the screen, making it perfect for fashion projects, documentary and sports. Capturing delicate facial details with exquisite precision, these lenses excel at mesmerizing close-ups that leave a lasting impression.

Cinematic Immersion with Artistic Colors
The Tango zoom series features advanced optical design to effectively correct chromatic aberrations, resulting in optimal image quality and color reproduction. The entire lineup maintains a high level of color consistency, along with outstanding distortion control and imperceptible breathing effects, ensuring an immersive visual experience with unrivaled brilliance.

Seamless Integration with MOVCAM Servo Unit (Optional)
The Tango Zoom series offers the ultimate combination of cinema-grade optics and ENG-style functionality. With optional servo compatibility, these lenses can be seamlessly integrated with ENG cameras, enabling remote control of focus, iris and zoom settings. Unlocking new possibilities for broadcasting, large-scale events, and versatile shooting scenarios, they cater to experienced cinematographers seeking professional-grade performance.

Fluorescent Markings for Practical Operation
Thoughtfully designed to accommodate the demands of low-light shooting, all focus ring, zoom ring, and aperture ring markings are coated with luminous paint. This ingenious integration enhances clarity, empowering focus pullers and camera operators to effortlessly discern crucial details above the lens, elevating on-set efficiency.

Technical Specifications

Name

Tango

Color

Black

Focal Length

18-90mm

65-280mm

Mount

PL/EF



Aperture

T2.9-T22

T2.9-4-T22

Image Circle

31.5mm (S35)



Construction of optics

24 elements 17 Groups

21 elements 17 Groups

Flange Distance

52mm(PL) / 44mm(EF)



Close Focus

0,7m/2ft3in

1,1m/3ft7in

Zoom Ratio

5x

4.31x

Iris Control

Manual (rotation angle 74.1°)

Manual (rotation angle 73.6°)

Focus Control

Manual (rotation angle 270°)



Zoom Control

Manual (rotation angle 100°)



Front Diameter

114mm/4.48in



Length

249.1mm/9,8‘‘ PL mount

256.4mm/10.1‘‘ EF mount

267.1mm/10,5‘‘ PL mount

274.4mm/10.8‘‘ EF mount

Iris Blade

16



Filter Size

M105



Gear Pitch

0.8 Mod



Material

Aluminium Alloy



Weight

3539g

3962g



Delivery Content:
1x DZOFILM Tango 18-90mm T2.9 for PL/EF Mount (S35) metric
1x DZOFILM Tango 65-280mm T2.9-4 for PL/EF Mount (S35) metric
2x PL mount
2x EF mount
2x front cap
2x Support Base
4x Support Rods
2x hard case

Servo-unit not included!
