Blackmagic Design Blackmagic 2110 IP Mini IP to HDMI

Blackmagic 2110 IP Mini IP to HDMI

This model connects large screen TVs or computer monitors to SMPTE-2110 IP systems. Its compact design allows for mounting behind the display. It supports SD, HD, and Ultra HD video standards up to 2160p60, making it future-proof. It has a standard 10G RJ-45 Ethernet connection, allowing the use of regular CAT-6 Ethernet cables. The converter can be powered via Ethernet (PoE) or with the included DC power supply.

• Conforms to SMPTE-2110 IP video standard.
• Available in Mini Converter or rack mount models.
• Uses 10G Ethernet for cost-effective installation.
• Re-syncs SDI inputs to a common PTP clock.
• Includes NMOS Protocol for building a virtual router.
• Low latency, open standard Blackmagic IP10 codec.
• Supports all SD, HD, and Ultra HD formats up to 2160p60.

The Blackmagic 2110 IP Converters integrate SDI equipment into 2110 IP broadcast systems. The rack mount models can be installed in equipment racks next to the equipment being converted. Adding converters provides a low-cost way to transition all video equipment to SMPTE-2110. Simply add a Blackmagic 2110 IP Converter to various equipment for seamless integration.

Features

• Conforms to SMPTE ST-2110 standard for IP video.
• Re-syncs SDI inputs to a common PTP clock.
• Uses 10G Ethernet for smaller, more affordable products.
• Supports SD, HD, and Ultra HD video standards.

In the Box

• 1x Blackmagic 2110 IP Mini IP to HDMI
• 1x DC power supply
• 1x Welcome wallet with QR code for software download
