Atomos AtomX Ultrasync One (ATOMXSYON1-ROW)

Atomos AtomX Ultrasync One (ATOMXSYON1-ROW)
Timecode System

UltraSync ONE introduces a whole new level of portability, versatility and control to wireless synchronisation. It’s super compact, lightweight, features an OLED display and is easy and cost-effective to use as part of a whole range of multicamera workflows, offering a robust sync solution whether you’re using film cameras or DSLRs, shooting in standard format or 360-degree VR.

• 20-40 hours battery life
• Cleverly concealed internal diversity antennas
• All sync modes – timecode, genlock & word clock
• Generate master timecode or configure as a slave
• Jam or slave to an external LTC source
• RF sync range of up to 200m
• Connect to BLINK Hub via a :pulse or :wave to enable remote status monitoring and control

Configure UltraSync ONE as a timecode master or timecode slave. Or alternatively jam to house timecode or an OB truck. The UltraSync experience is just as amazing whether you’re using DSLRs out on location, professional cameras in a studio, or on cameras configured for 360-degree filming in a VR rig. The robustness of our solution regardless of the set-up is down to using uncongested sub GHz frequency bands for a completely reliable synchronisation up to 200m.

In The Box
1x UltraSync ONE unit
1x USB C charging lead
1x Mini COAX to RA BNC (blue) for LTC
1x Mini COAX to RA BNC (red) for genlock

Specifications

Dimensions

5,5 x 4,4 x 1,7 cm

Weight

39 g

Range

approx. 200m

Display

128 x 32 pixels OLED Display

FPS

23.98, 24.00, 25.00, 30.0D, 29.97D, 29.97

Frequency

865.050 MHz to 923.200 MHz
