Laowa Proteus 2X Anamorphic 28mm T2 - Blue (Meters) Arri PL (Default) + EF

Laowa Proteus 2X Anamorphic 28mm T2 - Blue (Meters) Arri PL + EF

The Laowa Proteus cine lenses feature a patented anamorphic design, favored by professionals for their smooth oval bokeh and unique flares. With a constant 2x squeeze factor, they deliver an ultra-wide aspect ratio, essential in the film industry.

When used with a 43 sensor, the lens produces a cinematic 2.661 aspect ratio, while a 65 sensor yields a 2.41 ratio, both cropping to an ideal 2.391 aspect ratio. The lenses support the S35+ sensor format, covering the Alexa 35 and Red V-Raptor 7K sensors effectively.

The large T2 aperture facilitates low-light filming, providing sharp images and excellent background isolation, with optimal quality at T4. The close focus distance is just 48 cm, enhancing the characteristic thin and elongated bokeh typical of anamorphic lenses.

Available flare colors include Blue, Amber, or Silver.

Features

• Patented anamorphic design
• Constant 2x squeeze factor
• Large T2 aperture
• Short close focus distance
• Artistic oval bokeh
• Minimal focus breathing
• Outstanding sharpness
• Full-frame coverage with 1.4x extender
• Professional cine housing
• Available flare colors: Silver, Blue, Amber

Delivery Content

• 1x Proteus 2X Anamorphic 28mm T2 - Blue (PL-Mount)
• 1x EF mount
• 1x rear lens cap
• 1x front lens cap
• Shims
• Tools
• Lens support
• Case

Technical Specifications

• Focal Length: 28 mm
• 17 lens elements in 15 groups
• Horizontal angle of view: 85.6 degrees
• Vertical angle of view: 42.2 degrees
• Sensor type: S35
• Maximum aperture: T2
• Minimum aperture: T22
• 10 aperture blades
• Manual, stepless aperture adjustment
• Manual focus
• Close focus distance: 48 cm
• Filter thread: 105 mm
• PL mount (EF mount included)
• Dimensions: approx. 11.9 x 18.2 cm
• Weight: approx. 2400 g
